Coin Battery Electrode Material Vacuum Mixer Machine 110V 220V

MOQ : 1pcs

Payment Terms : T/T

Supply Ability : 10 pcs per week

Delivery Time : 10-15 work kdays

Packaging Details : Wooden box

Price : 100-10000USD，Negotiable

Contact Now

Coin Battery Electrode Material Vacuum Mixer Machine

This model is the latest model of all material vacuum mixers in our company. It has a new exterior design, touch switch, and electronic exhaust function. The machine stirs the application materials in a vacuum state, completely achieving no bubbles, thus improving the filling properties of the materials and the density of the model. This machine is equipped with a high-end vacuum pump, which has an extremely long service life. High vacuum degree, strong stirring force, adjustable amplitude, no bubbles in the embedded casting ring, uniform and high-density, perfect effect. This machine includes a technician oscillator, achieving dual-use and providing excellent value for money

XW-ZKJB-S is designed to produce coating slurry by mixing the small batch of chemical and compound (500 ml Max., up to 30000mPa.s) under vacuum to remove gas bubble and protect the sample from oxidation.

It has a built-in pump which can vacuum the mixing container to -0.08Mpa and the step-less mixing speed 320rpm. The vibration plate is located at the bottom to remove gas bubble before vacuum mixing and disperse the slurry after mixing. It is excellent for preparing battery electrode paste and various ceramic materials in a material research lab.

Parameters

Item	Parameter	Item	Parameter
Model	XW-VM-S	Voltage	AC110V/220V,50/60Hz
Power	150W	Rotary speed	0-320rpm
Mixing time	0-999 min	Vibration plate	Vibrating at 1000Hz
Size	330310510mm	Weight	30kg
Mixing container	1.Container size: 50ml, 150ml, stainless steel material, customized size 2.Mixing blade is built-in to the top of the container 3.Metal filter prevents solid particles from being sucked into the vacuum pump
Vacuum pump and Vacuum level	1.Built-in single stage vacuum pump 2.Vacuum level: -0.08~0.09Mpa
Application note	1.The main duty of this product is to remove the bubbles from the slurry during the wet mixing stage 2.For best slurry, you may consider ordering filter to remove larger particles in slurry
